HSP/MHP Multistage Centrifugal Pump
PWSHSP/MHP
Flow：1m³/h-90m³/h
Head：200m-1000m
Motor Power ：5.5KW-200KW
Inlet/Outlet Caliber ：DN25-DN80
Head：200m-1000m
Motor Power ：5.5KW-200KW
Inlet/Outlet Caliber ：DN25-DN80
Quantity
The HSP/MHP series represents a highly versatile range of multi stage pump designed to handle high-pressure water transport with exceptional efficiency. Depending on your specific spatial requirements and installation constraints, these units can be configured as either horizontal centrifugal pumps for easy maintenance and stability, or as vertical centrifugal pumps to minimize the physical footprint in tight industrial environments. Engineered for durability, they are the go-to solution for applications ranging from boiler feed systems to large-scale irrigation and industrial pressure boosting.
Product Features
Specialized Design
HSP (vertical) and MHP (horizontal) multi stage pump are custom-designed with mechanical seals and fluid components to withstand the high-pressure requirements of specific fluid solutions.
High-Pressure Capacity
Developed using cutting-edge technology, they achieve a breakthrough by reaching single-pump pressures up to 1000m³/h.
Developed using cutting-edge technology, they achieve a breakthrough by reaching single-pump pressures up to 1000m³/h.
High-Speed and High-Efficiency Operation
Equipped with a dedicated permanent magnet motor, they can achieve sustained high-speed operation at 5200rpm.
Equipped with a dedicated permanent magnet motor, they can achieve sustained high-speed operation at 5200rpm.
Structural Forms
Available in both vertical (HSP) and horizontal (MHP) configurations to suit different installation spaces and piping layouts.
Available in both vertical (HSP) and horizontal (MHP) configurations to suit different installation spaces and piping layouts.
Product Advantages
Extremely High Head/Pressure
A single pump can reach pressures of 1000m, far exceeding the pressure range of traditional pumps, making it suitable for industrial applications with extremely high pressure requirements.
Stable and Reliable Operation
The permanent magnet motor, combined with a 5200rpm design, ensures the pump's stability and reliability under long-term, high-speed operation.
Strong Fluid Compatibility
With custom-designed mechanical seals and fluid spare parts, the pump can safely and effectively transport specific fluid solutions, solving the problem of ordinary pumps handling special media under high pressure.
Technological Leadership
Utilizing cutting-edge technology in its research and development, the pump demonstrates the company's leading technological position in the field of high-pressure centrifugal pumps.
Application Scenarios
High-Rise Building Water Supply
In high-rise buildings, extremely high head is required to lift water to the top-floor residents, making multi-stage high-pressure centrifugal pumps ideal booster devices.
Fire Protection System Booster Pumps
As backup or main booster pumps for fire protection systems, they provide high-pressure, high-flow-rate water to meet firefighting needs in emergencies.
As backup or main booster pumps for fire protection systems, they provide high-pressure, high-flow-rate water to meet firefighting needs in emergencies.
High-Pressure Spray Irrigation
Used in large-scale agriculture or specialized greenhouses to drive high-pressure spray systems for precise irrigation, fertilization, or pest and disease control.
Used in large-scale agriculture or specialized greenhouses to drive high-pressure spray systems for precise irrigation, fertilization, or pest and disease control.
Other Demanding Industrial Processes
Suitable for all industrial environments with extremely high pumping pressure requirements and the need for customized handling of specific fluids, ensuring stable delivery of fluid solutions under high pressure.
Suitable for all industrial environments with extremely high pumping pressure requirements and the need for customized handling of specific fluids, ensuring stable delivery of fluid solutions under high pressure.
Installation and Adaptability
Structural Adaptability
HSP (Vertical): Suitable for locations with limited space or requiring vertical installation to save floor space.
MHP (Horizontal): Suitable for conventional installations or locations requiring easy maintenance.
HSP (Vertical): Suitable for locations with limited space or requiring vertical installation to save floor space.
MHP (Horizontal): Suitable for conventional installations or locations requiring easy maintenance.
Fluid Adaptability
Adaptable to the delivery requirements of specific fluid solutions, with customized design ensuring fluid media sealing and transmission efficiency under high pressure.
System Integration
Equipped with a high-speed permanent magnet motor, it can be integrated as a high-efficiency, compact booster system into various industrial equipment and pipelines.
